ERO 1480
Incremental modular rotary encoder without
integral bearing
Line count:             1024
Output signal:          ~1Vpp
Cutoff frequency (-3
dB):                    180.00 kHz
Power supply:           5 V (+-10 %)
Form of housing:        with opening for
                        connectable cable assembly
Shaft:                  Hollow shaft with radial
                        fastening, diameter 6 mm
Degree of protection:   IP00 (EN60529)
Operating temperature:  -10/+70 °C
Electrical connection:  Plug connector, straight,
                        double-row, 12-pin, with
                        locking mechanism and
                        walls (separate plug and
                        housing)
Pin configuration:      D297243
Connecting direction:   axial
Special characteristics,
rotational encoders:    none
Please pay attention to the product documentation!
