HEIDENHAIN 变频器   536565-01 UR 242D 22 40kW<4.0s

源头采购、质量保证、交货期短、价格优惠

UR 242D
Compact Inverter regenerative
With diagnostic functions and electronic ID lable
Rated current 5 kHz:         2 x 7.5A-axes and
                             7.5A-axis or
                             10A-spindle, 25A-axis
                             or 35A-spindle,
                             35A-spindle or
                             25A-axis
Max. current at 5 kHz:       3x 15A and 2x 50A
Rated power:                 22 kW
Power S6-40%:                30 kW
Peak power:                  40kW<4.0s
DC-link voltage:             650 V
Low-voltage power supply
unit:                        200 W
Type of heat removal:        internal
Connection for holding
brakes:                      with connection
Module width:                250.00 mm
Ribbon cables and cover for ribbon cables are
included in delivery
