RCN 2590F
Absolute angle encoder (singleturn) with integral
bearing and integrated stator coupling
System accuracy:          ±2.5''
Data interface:           Fanuc05
Positions per revolution: 268435456
Output code:              Binary
Power supply:             3.6 V ... 14 V
Shaft:                    Hollow through shaft for
                          axial clamping, diameter
                          20 mm
Flange version:           Rectangular flange with
                          85 mm centering collar,
                          drainage channels,
                          aluminum
Degree of protection:     IP64 (EN60529)
Operating temperature:    0/+50 °C
Max. mechanical
permissible
speed/rotational speed:   1500 1/min
Electrical connection:    Flange socket
                          Ultra-Lock, male, 12-pin
Pin configuration:        D680849
Connecting direction:     tangential
Special characteristics,
rotational encoders:      none
