LC 485
Absolute sealed linear encoder with small cross
section
Measuring length:       470 mm
Total length:           ML+138 mm
Accuracy grade:         ± 5.0 µm
Grating period:         20.000 µm
Measuring step 1:       10.0000 nm
Fastening type:         End block + mounting spar
End block:              12A
Output signal:          sinusoidal voltage signals
                        (1 Vpp)
Output code:            Binary
Data interface:         EnDat02 Synchronous serial
                        EnDat 2.2 with incremental
                        signals
Power supply:           3.6 V ... 14 V
Electrical connection:  Flange socket, male,
                        14-pin
Special characteristics,
linear encoder:         none
