LC 485
Absolute sealed linear encoder with small cross
section
Measuring length:       220 mm
Total length:           ML+138 mm
Accuracy grade:         ± 5.0 µm
Grating period:         20.000 µm
Measuring step 1:       10.0000 nm
Fastening type:         End block + mounting spar
End block:              12A
Output signal:          sinusoidal voltage signals
                        (1 Vpp)
Output code:            Binary
Data interface:         EnDat02 Synchronous serial
                        EnDat 2.2 with incremental
                        signals
Power supply:           3.6 V ... 14 V
Electrical connection:  Flange socket, male,
                        14-pin
Special characteristics,
linear encoder:         none

LC 193F/50nm ML 1340mm ID 557676-13

LC 193F/50nm ML 1440mm ID 557676-14

LC 193F/50nm ML 1540mm ID 557676-15

LC 193F/50nm ML 1640mm ID 557676-16

LC 193F/50nm ML 1740mm ID 557676-17

LC 193F/50nm ML 1840mm ID 557676-18

LC 193F/50nm ML 2040mm ID 557676-19

LC 193F/50nm ML 2240mm ID 557676-20

LC 193F/50nm ML 2440mm ID 557676-21

LC 193F/50nm ML 2640mm ID 557676-22

LC 193F/50nm ML 2840mm ID 557676-23

LC 193F/50nm ML 3040mm ID 557676-24
