LC 485
Absolute sealed linear encoder with small cross
section
Measuring length:       770 mm
Total length:           ML+138 mm
Accuracy grade:         ± 5.0 µm
Grating period:         20.000 µm
Measuring step 1:       10.0000 nm
Fastening type:         End block + mounting spar
End block:              12A
Output signal:          sinusoidal voltage signals
                        (1 Vpp)
Output code:            Binary
Data interface:         EnDat02 Synchronous serial
                        EnDat 2.2 with incremental
                        signals
Power supply:           3.6 V ... 14 V
Electrical connection:  Flange socket, male,
                        14-pin
Special characteristics,
linear encoder:         none

C 193F/50nm ML 440mmID 557676-04

LC 193F/50nm ML 540mmID 557676-05

LC 193F/50nm ML 640mmID 557676-06

LC 193F/50nm ML 740mmID 557676-07

LC 193F/50nm ML 840mmID 557676-08

LC 193F/50nm ML 940mmID 557676-09

LC 193F/50nm ML 1040mmID 557676-10

LC 193F/50nm ML 1140mmID 557676-11

LC 193F/50nm ML 1240mmID 557676-12

LC 193F/50nm ML 1340mmID 557676-13

LC 193F/50nm ML 1440mmID 557676-14

LC 193F/50nm ML 1540mmID 557676-15

LC 193F/50nm ML 1640mmID 557676-16

LC 193F/50nm ML 1740mmID 557676-17
