LS 187C
Incremental sealed linear encoder with large
cross section
Measuring length:       2840 mm
Accuracy grade:         ± 3.0 µm
Grating period:         20.000 µm
Fastening type:         Screw-on strip integrated
Output signal:          sinusoidal voltage signals
                        (1 Vpp)
Reference mark position:Distance-coded reference
                        marks with nominal
                        increment 1000 x grating
                        period
Further reference marks:none
Power supply:           5V+-5%
Electrical connection:  Flange socket, male,
                        14-pin
Special characteristics,
linear encoder:         none
