LC 185
Absolute sealed linear encoder with large cross
section
Measuring length:       440 mm
Accuracy grade:         3.0 µm
Grating period:         20.000 µm
Measuring step 1:       5.0000 nm
Fastening type:         Screw-on strip integrated
Data interface:         EnDat02 Synchronous serial
                        EnDat 2.2 with incremental
                        signals
Power supply:           3.6 V ... 14 V
Electrical connection:  Flange socket, male,
                        14-pin
Special characteristics,
linear encoder:         none
