LB 382C
Incremental sealed linear encoder with large
cross section for measuring lengths up to 3040mm
(complete unit, one-piece)
Measuring length:       2840 mm
Accuracy grade:         ± 5.0 µm
Grating period:         40.000 µm
Fastening type:         Standard
Output signal:          sinusoidal voltage signals
                        (1 Vpp)
Reference mark position:Distance-coded reference
                        marks with nominal
                        increment 2000 x grating
                        period
Power supply:           5V+5%-10%
Electrical connection:  separate adapter cable
Special characteristics,
linear encoder:         none
