海德汉HEIDENHAIN ID 557679-23 型号 LC 183 2840 5,0 EnDat02 10 D I 0MS14 .. ~1Vss 7C 01 .. 32 ..

参数   LC 183 封闭式光栅尺 现货

LC 183
Absolute sealed linear encoder with large cross
section
Measuring length:       2840 mm
Accuracy grade:         5.0 µm
Grating period:         20.000 µm
Measuring step:         10 nm
Fastening type:         Screw-on strip integrated
Data interface:         EnDat02 Synchronous serial
                        EnDat 2.2 with incremental
                        signals
Power supply:           3.6V..5.25V
Electrical connection:  Flange socket, male,
                        14-pin
