KGM 182
Grid encoder;
consisting of:          Plate with two coordinate
                        phase grating
                        scanning unit
                        (for 2-measuring
                         directions)
                        transport case
Diameter:               230mm
Accuracy grade:         +/- 2 µm in longitudinal
                        and orthogonal direction
Signal period:          0,004 mm
Output signal:          sinusoidal voltage
                        signals (1 Vpp)
Power supply:           5V+-5%
Electrical connection:  via APE with D-sub
                        connector
                        1m cable between scanning
                        head and D-sub connector
Note:
Subsequent electronic, adapter cable and eva-
luation software have to be ordered separately

LC 193F/50nm ML 540mm ID 557676-05

LC 193F/50nm ML 640mm ID 557676-06

LC 193F/50nm ML 740mm ID 557676-07

LC 193F/50nm ML 840mm ID 557676-08

LC 193F/50nm ML 940mm ID 557676-09

LC 193F/50nm ML 1040mm ID 557676-10

LC 193F/50nm ML 1140mm ID 557676-11

LC 193F/50nm ML 1240mm ID 557676-12

LC 193F/50nm ML 1340mm ID 557676-13

LC 193F/50nm ML 1440mm ID 557676-14

LC 193F/50nm ML 1540mm ID 557676-15

LC 193F/50nm ML 1640mm ID 557676-16

LC 193F/50nm ML 1740mm ID 557676-17

LC 193F/50nm ML 1840mm ID 557676-18

LC 193F/50nm ML 2040mm ID 557676-19

LC 193F/50nm ML 2240mm ID 557676-20

LC 193F/50nm ML 2440mm ID 557676-21

LC 193F/50nm ML 2640mm ID 557676-22

LC 193F/50nm ML 2840mm ID 557676-23

LC 193F/50nm ML 3040mm ID 557676-24
