EIB 741
External interface box with serial output
interface for incremental and absolute encoders
Number of measured axes:  4
Input signal:             Sinusoidal signals (1
                          Vpp, 11 µApp) / EnDat
                          2.1 / EnDat 2.2
Connection measuring      4 x 1Vpp or 4 x EnDat
systems:                  2.1 or 4 x EnDat 2.2
Electrical connection:    Built-in D-sub connector
                          without housing, 2-row,
                          female, 15-pin
Output interface:         Ethernet
Electrical connection 3:  Mounting box RJ45,
                          female, 8-pin
Additional interface:     4x RS485 in + 4x RS485
                          out
Electrical connection,    D-sub connector
combination:              female/male 9-pin
Power supply:             100 ... 240 Vac (+-10
                          %), 50 ... 60 Hz (+-2
                          Hz)
Electrical connection 5:  Inlet connector for
                          non-heating apparatus,
                          male 3-pin
Degree of protection:     IP20 (EN60529)
Special characteristics,  Documentation, drivers,
interface electronics:    and examples are
                          available for free
                          downloading at
                          www.heidenhain.de

LC 195F Fanuc05 ML 140mm ID 760907-01。

LC 195F Fanuc05 ML 240mm ID 760907-02

LC 195F Fanuc05 ML 340mm ID 760907-03

LC 195F Fanuc05 ML 440mm ID 760907-04

LC 195F Fanuc05 ML 540mm ID 760907-05

LC 195F Fanuc05 ML 840mm     ID 760907-08

LC 195F Fanuc05 ML 940mm ID 760907-09

LC 195F Fanuc05 ML 1040mm   ID 760907-10

LC 195F Fanuc05 ML 1140mm   ID 760907-11

LC 195F Fanuc05 ML 640mm ID 760907-12

LC 195F Fanuc05 ML 740mm ID 760907-13

LC 195F Fanuc05 ML 1440mm   ID 760907-14

LC 195F Fanuc05 ML 1540mm   ID 760907-15

LC 195F Fanuc05 ML 1640mm   ID 760907-16

LC 195F Fanuc05 ML 1740mm   ID 760907-17
